Fits: Sovol SV08 and VORON Design 350 V2

(Please see full printer list below on the ‘Fits & Contents’ tab)

Description Fits & Contents Installation Use

Our XTR high strength Magnetic Base for FDM is an extra thick, 2 mm magnet that improves the already most powerful FDM magnet available on the market. Our eXTReme line is designed for the increased performance needed on Prosumer and Industrial machines to provide more stiffness to resist peel and bending forces that come with using engineering grade filaments. These powerful, temperature resistance magnets ensure the build plate stays perfectly aligned during printing and come pre-backed with high-temperature 3M adhesive for easy installation. XTR is the ultimate solution for superior performance and reliability in FDM printing. Explore more info on the Flexible Build System.

+Printer Fits

Printer Fits:
Sovol SV08
VORON Design 350 V2

May fit:
Sovol SV03
Zortrax M300

Do you have a printer similar to what’s listed under Printer Fits or May Fit?
If you have a printer similar to the one described above and believe our solution could work for your printer, please follow our easy instructions on measuring your build plate. Let us know if your printer matches our specifications or is even close! Wed love to hear about it, and you might even receive a discount on Wham Bam merchandise for your efforts. Click here for more info.

+Contents & Tech Info Includes:

• 1 XTR Magnetic Base

Dimensions:

• 355 x 355 mm
• Magnetic Base 2 mm

Heat Limits:
Magnetic Base with 3M Glue rated to 150C continual use

+Magnetic Base Install

Please follow these steps when applying a new Magnetic Base:

1. Remove old magnet (if any), and clean the bed well to remove any glue. Use isopropyl alcohol and a fresh paper towel.
2. Use 220 grit sandpaper to rough up the metal surface uniformly and remove any excess contaminants. If your surface is painted, try to break through the paint layer with the sandpaper at least partially.
3. Clean with 90% isopropyl alcohol and a fresh paper towel. Repeat with alcohol and a fresh paper towel a few times until the paper towel comes away clean. Do not use shop rags, wipes, etc., as these will propagate contaminants back to the surface. Use only fresh paper towels.
4. Let the bed completely dry before applying the magnet.
5. Let 3M cure for a full 72 hours before use.

Magnetic Base install video clip:

+Level after install

If your machine has automatic bed leveling, run the leveling process and set your gap such that the first layer is well squished. For more details on achieving the right first layer squish, refer to this bed leveling guide.

If your printer uses manual leveling, follow the same guide for instructions on the leveling process.

Full support info can be found on our support page.
