Part of our EDUKIT range

Starting from an already made example program, this module will teach you how to:

• Read up to 8 push buttons and activate a PC event
• Light up to 8 LEDs using your PC
• Read the value of 2 different potentiometers (analog value)
• Read and display the temperature on the PC
• Read the value of a temperature dependent resistor (NTC)
• Read the value of a light dependant resistor (LDR)
• Dim a white LED using your PC
• Learn how to display text on an LCD using your PC
• Learn how to combine the above and use the LCD to display push button press, display values..

Specifications

• USB powered + LED indicator
• PC with windows XP or higher (internet needed for software download)
• Digital input/output:
• 8 definable push buttons
• 8 definable LEDs
• 1 White LED
• Analog input:
• Temperature sensor
• NTC resistor
• LDR resistor
• 2 potentiometers

Display:

• 16 character 1 line LCD

Includes:

• USB cable
• Board dimensions: 75 x 75mm / 3×3″
